Disaster Area Designs DPC-5 Gen3
Programmable Audio & Midi Switcher

Como novo. Pouco uso (apenas estúdio). Descontinuado. Raro.
Provavelmente o controlador audio & midi mais compacto do mercado.

→ Perfeito para pedalboards "pequenas/médias" mas com grande capacidade sónica e um misto de pedais analógicos + pedais MIDI, Amp switching, etc...

→ 5 audio loops programáveis para pedais não-MIDI
→ Controlo até (4) pedais MIDI via 5-Pin MIDI output ou 1/4" Jack Output (Chase Bliss, Empress, Strymon, etc...)

- Tap tempo (jack/midi)
- EXP/FW input
- TRS Amp Channel Switching
- Always active Tuner out
- Multi-Jack Output (FAV, Analog TAP, MIDI)
- USB port (DAW control)
- Looper control

—
TERMOS & CONDIÇÕES:
→ Recolha em mão no Porto/Matosinhos (3min do NorteShopping)
→ Envio com portes a cargo do comprador e pagamento prévio (MB Way / Transferência Bancária).
→ SEM INTERESSE EM TROCAS... mas posso considerar Delays & Reverbs, Nord Stage 3/4, Oktatrack/Digitakt, PolySynths analógicos ou material de Estúdio (prés/comps/eq's/mics). Propostas por mensagem. Obrigado

—
The Disaster Area Designs DPC-5 Gen3 can control a mix of MIDI and non-MIDI pedals in your rig, allowing you to craft presets that you can engage instantly when you need them. A single tap on your DPC-5 can turn up to five non-MIDI pedals on or off, send tap tempo to a delay or other device, change the channel on your amplifier, and switch programs on up to four MIDI devices.

TRS Amp Control
The white jack above the main output is an isolated switching output, designed to control amplifier functions or other remote switching tasks. Almost anything that uses a 1/4” input for foot switching may be controlled by the TRS Amp Control jack.

Tuner Mute
The DPC-5 has a hardware tuner output, which is a buffered copy of the signal from the main input. The tuner output is always active. This will silence the main output but the tuner output stays active.
Optionally, if one of your MIDI pedals is equipped with a tuner function then the DPC-5 Gen3 can activate this instead.

"D" Footswitch Assign
This footswitch may be assigned to a variety of destinations in Preset Mode. By default, we map this footswitch to Tap Tempo / Clock but you can change it to one of three options:

TAP - The D footswitch sends tap tempo commands. If the CLK mode is disabled or set to TAP, then taps are send as MIDI CC
messages. If CLK is set to PST or GLB, then tapping this footswitch will control the DPC-5 internal SMARTClock function.

FAVE - The D footswitch acts as a Favorite switch, tapping it engages the Favorite preset or returns to the previous setting if the Favorite preset was active.

PRST - The D footswitch recalls the fourth preset in each preset bank, allowing the user to access four presets instead of the
usual three in each bank.
