Sound Output Mode: Surround Sound
Audio D/A Converter: 24bit / 96kHz
Built-in Decoders: DTS decoder, Dolby Digital, Dolby Pro Logic II
Surround System Class: 5.1 channel
Digital Sound Processor (DSP)
DSP Presets: All Ch Stereo, Orchestra, Studio-Mix, TV Logic, Unplugged
Additional Features: A/B/A+B speaker switch, Midnight Mode, digital signal format auto detection / auto switching, mute button, on-screen display
Bass Control
Treble Control
Built-in Clock: sleep timer

AMPLIFIER
Input Impedance:50 KOhm
Input Sensitivity: 200 mV

AMPLIFIER OUTPUT DETAILS
Output Power / Channel: 85 Watt
Output Impedance / Channe: l6 Ohm
Total Harmonic Distortion (THD): 0.08 %
Channel Type: center, front, surround
Channel Qty: 1, 2

RADIO
Tuner Type: digital
Tuner Bands: AM/FM

INPUTS & OUTPUTS
Headphone Jack
Coaxial Digital Input
Optical Digital Input

REMOTE CONTROL
Type: universal remote control
Remote Control Technology: infrared

ACCESSORIES
Supported Devices: AV receiver, CD player, DVD player, TV, VCR, cassette deck
Features: multi-brand compatibility, programmable

AUDIO SPECIFICATIONS
Type: Amplifier, Radio tuner

CONNECTIONS
Qty1, 2, 3
Type5.1 channel audio line-in, AM antenna, FM antenna, S-Video input, S-Video output, SPDIF input, audio line-in, audio line-out, center speaker output, composite video input, composite video/audio input, composite video/audio output, front speakers output, headphones, monitor output, rear speakers output, remote control, subwoofer output
Connector Type4 pin mini-DIN, F connector, RCA, RCA x 2, RCA x 3, RCA x 6, TOSLINK, banana/spade x 2, click-fit x 2, mini-phone 3.5 mm, phone stereo 6.3 mm
Connector Locationfront, rear

DIMENSIONS & WEIGHT
Depth: 14.8 in
Width: 17.1 in
Height: 5.9 in
Weight: 19.4 lbs
